Remote Control For Roller Shutter
The Futai's China Remote Control for Roller Shutter is an electronic device that achieves remote control of a target device through wireless signal transmission. It mainly consists of a transmitter (remote control, mobile phone, sensor, etc.) and a receiver (controller, actuator). Its working principle is: the transmitter encodes user commands (such as switching, adjusting, or mode changing) into specific signals (radio frequency, Bluetooth, etc.) and transmits them to the receiver via a wireless medium; the receiver decodes the signal and drives the actuator (motor, lighting, home appliances, etc.) to complete the operation.
Product Parameter (Specification)
| Signal Type | RF: 433MHz, Non-linear, highly penetrativeWi-Fi: 2.4GHz, connected to network, remote control (accessible globally) | Determines transmission distance, anti-interference capability, and applicable scenarios (RF is suitable for industrial/smart home use). |
| Electrical parameters | Operating Voltage: Transmitter (Battery powered: CR2032/AA/18650, etc., voltage 1.5V-12V; rechargeable: 5V USB); Receiver (AC 220V/110V, DC 5V/12V/24V, PoE powered) | For battery-powered models, pay attention to battery life (e.g., CR2032 lasts about 1 year, AA batteries about 3 months); the receiver must match the power supply of the controlled device. |
| Control Distance | RF: 20-100 metersWi-Fi: Depends on the router (30-50 meters indoors, wide coverage outdoors) | In practice, obstacles (walls, metal) and interference sources (Wi-Fi, microwave) can have an impact, so redundancy should be allowed. |
| Protocal | Code: fixed code, learning codeProtocal: Dooya | Learning code suitable for networking multiple devices |
| Function | Channel: 1-15 channelAdditional features: scheduled control, scene mode (execute multiple commands with one click), status feedback (receives operational status from the device), voice control (compatible with Alexa/Google Home) | Multi-channel support for complex scenarios (such as smart home 'coming home mode': turning on lights, air conditioning, and curtains); status feedback enhances reliability |
Product Feature and Application
Remote control for Roller Shutter Feature:
1.Flexibility: Overcomes spatial limitations, supports long-distance control (such as RF remote-controlled industrial roller shutters) or non-line-of-sight control (RF/Bluetooth penetrating walls), and adapts to complex environments (such as warehouses and basements).
2.Compatibility: Supports multiple protocols (RF dual-mode), multiple devices , and some high-end models can define functions via software ("custom buttons").
3.Reliability: Industrial-grade solutions use anti-interference chips (such as TI CC1101 RF chip, Nordic nRF52 Bluetooth chip), operate in a wide temperature range of -40℃ to 85℃, resist static electricity (ESD≥8kV), and withstand electromagnetic interference (EMC certified).
4.Intelligence: Networked (Wi-Fi/Bluetooth) devices support remote control via mobile apps (such as turning off the home roller blinds while traveling), cloud storage (logging operation history), and AI interaction (light sensors triggering curtain opening and closing).
5.Low Power Consumption: Low-power protocols like Bluetooth BLE and Zigbee, with transmitters using button batteries lasting 1-5 years (e.g., Xiaomi Mijia Bluetooth remote), and receiver standby power consumption ≤0.5W (energy-saving design).
Application
Industrial door/ Garage Door/ Swimming pool/ Roller blinds at home/ shopping mall/ Farmhouse etc.
